[10 CON] Triac Dán MCR100-8 SOT-23 1A 600V (SMD Dán) (100-8)

Giới thiệu [10 CON] Triac Dán MCR100-8 SOT-23 1A 600V (SMD Dán) (100-8)

Triac Dán MCR100-8 SOT-23 1A 600V (SMD Dán) (100-8)

Mô tả:
Description
TRANS NPN 600V 1A SOT-23

Thông số kỹ thuật:
- Maximum peak gate power (PGM): 0.01 W
- Maximum repetitive peak and off-state voltage (VDRM): 600 V
- Maximum average on-state current (IT(AVR)): 1 A
- Maximum RMS on-state current (IT(RMS)): 1 A
- Non repetitive surge peak on-state current (ITSM): 10 A
- Critical repetitive rate of rise of on-state current (dI/dt): 50 A/µs
- Critical rate of rise of off-state voltage (dV/dt): 35 V/µs
- Maximum operating junction and storage temperature range (Tstg, Tj): -40..110 °C
- Junction to ambient thermal resistance (RTH(j-a)): 200 K/W
- Junction to case thermal resistance (RTH(j-c)): 50 K/W
- Triggering gate voltage (VGT): 1 V
- Peak on-state voltage drop (VTM): 1.6 V
- Triggering gate current (IGT): 0.2 mA
- Holding current (IH): 2 mA
- Package: SOT-23

Datasheets:
https://alltransistors.com/scr/datasheet.php?pdf=MCR100-8
..............................................................................
